Deep Q Learning w/ DQN - Reinforcement Learning p.5

Deep Q-learning replaces the classic Q-table with a deep neural network that outputs Q-values for every possible action, letting reinforcement learning handle far more complex environments than discrete tables can manage. Instead of storing and updating a value for each state-action pair, the network takes an observation (often an image, but it can also be feature values like Δx/Δy) and produces a vector of Q-values—one per action. The agent then chooses the action with the highest predicted Q-value (via argmax), while exploration is handled with an epsilon-greedy strategy that sometimes picks a random action.

The core motivation is scalability. Q-learning relies on a discrete “observation space” and a discrete “action space,” and the memory required for a Q-table grows explosively as either space expands. Even small increases in the number of possible states or actions can make the table impractically large. Deep Q-networks avoid that by learning a function approximation: they can generalize across similar-but-not-identical situations. Where a Q-table might fail on a scenario outside its previously seen discrete combinations (forcing random behavior), a neural network can still produce meaningful outputs by recognizing patterns that resemble earlier experiences.

That generalization comes with tradeoffs. Training deep Q-learning is slower and more finicky than filling a Q-table. The brute-force “populate the table” approach can take minutes for small problems, while deep Q-learning can take hours for comparable setups. In exchange, deep Q-learning can tackle environments where Q-tables would require absurd amounts of memory—situations that would otherwise be measured in petabytes.

To stabilize learning, the method introduces two key engineering ideas. First, it uses a separate target network. One model is trained continuously, while a second “target” model is used to generate more consistent predictions; periodically, the target network’s weights are updated to match the main model. This reduces the feedback loop instability that can happen when the same network both predicts and learns from rapidly changing targets.

Second, it uses experience replay via a replay memory buffer (implemented as a fixed-length deque). Each agent step stores a transition containing the current observation, chosen action, received reward, next observation, and a terminal flag. Rather than training on the most recent single transition, the algorithm later samples random minibatches from this buffer. That breaks correlations between consecutive experiences and improves training stability, even though the model still gets updated frequently.

The transcript then moves into code structure for a DQN agent. It defines a convolutional neural network using Keras/TensorFlow components: Conv2D layers, ReLU activations, MaxPooling2D, Dropout, a Flatten layer, and Dense layers that end with a linear output sized to the action space. The network is compiled with mean squared error loss and an Adam optimizer with a learning rate of 0.001. The agent class creates both the main model and the target model (initially copying weights), sets up replay memory with a capacity of 50,000 transitions, and configures TensorBoard logging using a modified TensorBoard callback to avoid creating a new log file on every fit call.

Finally, it sketches helper methods: one to append transitions into replay memory and another to compute predicted Q-values for a given state, including input normalization by dividing by 255. Training itself is deferred to the next installment, but the groundwork—model, target network, replay buffer, and Q-value inference—is laid for implementing the DQN update rule.
