Local RAG with Llama 3.1 for PDFs | Private Chat with Your Documents using LangChain & Streamlit

A fully local “chat with your PDFs” system can be built using open models and self-hosted infrastructure, with responses grounded in retrieved document passages and accompanied by ordered source snippets. The core payoff is privacy and control: PDFs are ingested, chunked, embedded, and stored locally, then every question triggers retrieval, reranking, optional LLM-based filtering, and finally an answer generated strictly from the most relevant context.

The pipeline starts when a user uploads a PDF. Text extraction converts the PDF into plain text, then chunking breaks that text into smaller segments to stay within model context limits and improve relevance. Embeddings turn each chunk into a vector representation, which is stored in a local vector database (Quadrant via its local client). This creates a private knowledge base that can be queried without sending document content to a third party.

When a question arrives, a retriever pulls the top five most similar chunks from the vector store using similarity search. To improve ordering and accuracy, the system can add two additional stages. First, a reranker reorders the retrieved chunks so the most relevant passage is placed first—important because the downstream prompt is instructed to treat the first context as the most relevant. Second, an optional “chain filter” uses an LLM check to keep only passages that actually answer the question. In the demo, this filtering can collapse multiple candidates down to a single best chunk, reducing noise and helping the model avoid irrelevant or conflicting information.

Answer generation happens through a LangChain question-answering chain that feeds the user’s question plus the selected context into a local LLM. The system prompt instructs the model to use the provided contextual information, return concise answers when the answer is present, and format the output in Markdown. Context is assembled with the most relevant sources first, and the chain also supports chat history so follow-up questions can reference earlier turns.

The implementation ties these components together in a Streamlit interface. The app caches the built retrieval/QA resources so models and indexes aren’t rebuilt on every UI refresh. It streams the model’s response token-by-token and simultaneously captures retrieval events so the UI can display the exact source chunks used—rendered as expandable items alongside the final answer.

For local inference, the setup uses Llama 3.1 (via an open model served locally) and Gemma 2 as part of the retrieval/QA stack, with embeddings and reranking handled by Fast embeddings and a fast re-ranker. The PDF extraction choice is PDF2 (via the PDF2 library from Google engineers), justified through benchmark comparisons that weigh extraction speed and extraction quality.

A practical test uses a technical Porsche 2025 car PDF, including questions like engine specs, acceleration, and number of seats. With reranking and chain filtering enabled, the system returns answers that match the expected facts, and the UI shows the specific retrieved passages that supported each response. Deployment is demonstrated via Streamlit Community Cloud, with configuration steps that avoid running heavy local-only services remotely and instead rely on exported requirements and Streamlit secrets for any optional remote API keys.
