Matplotlib Tutorial (Part 1): Creating and Customizing Our First Plots
Based on Corey Schafer's video on YouTube. If you like this content, support the original creators by watching, liking and subscribing to their content.
Install Matplotlib with pip install matplotlib, then import pyplot as PLT for plotting.
Briefing
Matplotlib is positioned as a practical way to turn Python data into clear, customizable charts—starting with a basic line plot and quickly layering in the elements that make a graph usable: titles, axis labels, legends, styling, and layout fixes. The core workflow is straightforward: install the library with pip, import pyplot as PLT, prepare x/y data arrays, plot with PLT.plot, and render with PLT.show. From there, the tutorial focuses on turning an “it works” chart into something that communicates meaning.
The first plot uses age ranges (25–35) as the x-axis and median salaries as the y-axis, with the salary data sourced from the Annual Stack Overflow Developer Survey (2019 data). After plotting, the chart is intentionally bare—no title or axis labels—so the next step is adding context. A chart title is added via PLT.title, and axis descriptions are added with PLT.xlabel and PLT.ylabel (including “USD” in the y-axis label). This transforms the figure from a generic line into a readable visualization that someone else can interpret without guessing what the axes represent.
Next comes comparison: a second line is added for Python developers’ median salaries by age. The tutorial then addresses a common usability problem—multiple lines without explanation—by adding a legend. Two legend approaches are shown: passing legend entries manually in a fixed order (works but is error-prone), and a better method that attaches labels directly in each PLT.plot call (label=...), letting PLT.legend automatically match the plotted lines. That “self-documenting” pattern also pays off later when the plotting order changes.
The styling section moves from “default look” to deliberate design. It demonstrates three ways to control line appearance: (1) compact format strings (color/marker/line style), (2) explicit keyword arguments like color= and linestyle=, and (3) hex color codes for more flexible palettes. Line width is adjusted with line width= to emphasize language-specific series (Python and JavaScript) while keeping the general “all developers” line thinner. Markers are briefly introduced as an option but then removed when they don’t suit the chart.
To improve readability, the tutorial adds PLT.tight_layout to fix padding issues across screen sizes and PLT.grid(True) to make it easier to see where lines intersect. It then shifts to Matplotlib’s built-in styling system: PLT.style.use with named styles such as “538,” “seaborn,” and “ggplot,” showing how those presets change colors, backgrounds, and grid behavior. A fun alternative style is introduced with PLT.xkcd, which mimics the hand-drawn look of xkcd comics.
Finally, the tutorial shows practical output handling: saving figures with PLT.savefig (e.g., plot.png) and expanding the dataset from the limited 25–35 slice to the full age range (18–55) that meets a minimum data threshold. The larger plot reveals that Python’s salary advantage is most pronounced in the mid-20s to mid-30s, then narrows as other languages catch up. The session closes by previewing future chart types (bar, pie, scatter, histogram, stack plots, time series) and data loading from CSVs, while also promoting Brilliant as a learning supplement for statistics and Python-based analysis.
Cornell Notes
Matplotlib is introduced through a step-by-step path from a bare line chart to a publication-ready visualization. The workflow starts with installing matplotlib, importing pyplot as PLT, preparing x/y lists, plotting with PLT.plot, and rendering with PLT.show. Usability upgrades include adding a title, labeling axes, and creating a legend—preferably by using label= in each PLT.plot call so PLT.legend stays correct even if plotting order changes. The tutorial then customizes appearance using explicit styling (color, linestyle, line width, optional markers), hex colors, grid lines, and PLT.tight_layout to prevent clipping. Built-in styles via PLT.style.use (including “538,” “seaborn,” “ggplot”) and the playful PLT.xkcd option demonstrate how quickly overall aesthetics can be changed.
What is the minimal Matplotlib recipe for a line plot, and what does each step accomplish?
Why is adding legend entries via PLT.legend(list) more fragile than using label= in PLT.plot?
How does the tutorial customize line appearance without relying on hard-to-read format strings?
What practical steps improve readability and layout across different screens?
How do Matplotlib styles and the xkcd option change the look of plots?
What does expanding from the 25–35 age subset to the full 18–55 dataset reveal?
Review Questions
- When would you prefer label= in PLT.plot over manually passing legend entries to PLT.legend, and what failure mode does it prevent?
- Which combination of commands helps prevent clipped labels and improves value estimation on the chart?
- How do PLT.style.use and PLT.xkcd differ in what they change about a plot’s appearance?
Key Points
- 1
Install Matplotlib with pip install matplotlib, then import pyplot as PLT for plotting.
- 2
Create two aligned lists for x and y values, then plot with PLT.plot(x, y) and display with PLT.show.
- 3
Make charts interpretable by adding PLT.title plus PLT.xlabel and PLT.ylabel.
- 4
Add legends reliably by using label= in each PLT.plot call and then calling PLT.legend without manually specifying an order.
- 5
Use explicit styling arguments (color, linestyle, line width) and hex colors to control appearance clearly.
- 6
Improve readability with PLT.tight_layout to fix padding/clipping and PLT.grid(True) to add reference lines.
- 7
Apply global aesthetics with PLT.style.use (e.g., '538', 'seaborn', 'ggplot') or switch to a comic-like look with PLT.xkcd, and save outputs using PLT.savefig.
