Printing Large Excalidraw Diagrams? This is the Script You NEED! The Printable Layout Wizard

TL;DR

Use the Printable Layout Wizard’s frame grid to control where Excalidraw elements are cut across pages, avoiding the unpredictable results of “fit to pages” exporting.

Briefing Cornell Notes

Briefing

Exporting an Excalidraw diagram to a multi-page PDF can produce awkward cut points where shapes get sliced across page boundaries. The Printable Layout Wizard script fixes that by letting users define explicit page frames, so printing follows the frame borders and keeps figure splits “nice and neat.” Instead of relying on a one-click “fit to four pages” export, users create a set of frames (for example, four frames arranged as a grid), then resize or reposition the diagram elements until the layout looks right within those frame boundaries.

The wizard also gives control over page ordering. Each frame carries a page number, and printing proceeds in alphabetical order based on frame names. Renaming a frame to something like “xxx” pushes it to the end of the print sequence, which is useful when the visual reading order differs from the default arrangement. For documents that include unused space, the script includes a “print empty pages” toggle: turning it off keeps the output to only the populated pages in sequence, while turning it on includes trailing blank pages—behavior that matters when templates intentionally reserve space.

Once frames are set up, the output can be cleaned up for presentation. Frame names (page labels) can be hidden through the Obsidian command palette by opening “Excel frame settings” and disabling the frame name display. This keeps the diagram view uncluttered while preserving the frame structure needed for correct printing.

The wizard supports both standard and custom page sizes, but with one constraint: every frame must be the same size. Users can create a custom-sized frame using the frame tool, then replicate that exact size across additional frames in the page manager. Printing then respects the chosen frame dimensions, ensuring the PDF matches the intended paper layout.

Templates are a major payoff. In Obsidian, users can configure a template file or folder, open the Printable Layout Wizard, and pre-build a multi-frame layout (such as five pages down and five pages across). Frame settings can be adjusted for template cleanliness—for example, hiding the frame name while keeping the outline. After saving the template (with Ctrl+S to ensure settings persist), new Excalidraw drawings automatically inherit the frame grid. Printing a new drawing then produces consistent multi-page output—such as a circle cut into four equal pages—without manual frame setup each time.

Finally, installation is handled through Obsidian’s tools panel. Users open the installer/update scripts area, find the layout wizard entry, and install or reinstall it. The script then appears in the tools panel, where users can long-press to pin it to the right-hand side for quick access. The overall result is a repeatable, controllable workflow for printing large Excalidraw diagrams with predictable page breaks and template-driven consistency.

Cornell Notes

The Printable Layout Wizard script improves multi-page Excalidraw printing by replacing “fit to pages” exporting with a frame-based layout. Users create a set of page frames (e.g., a 2x2 grid for four pages), resize the diagram, and then print so shapes are cut along the defined frame borders. Frame names control print order via alphabetical sorting, and a “print empty pages” option determines whether blank template pages are included. The wizard can hide frame name labels for a cleaner view, supports custom page sizes as long as all frames match, and enables reusable templates so new drawings automatically print in the same multi-page layout. Installation happens through Obsidian’s script installer, with optional pinning for fast access.

How does the Printable Layout Wizard prevent awkward cut points when printing large Excalidraw diagrams?

Instead of exporting a PDF with “fit to four pages,” the wizard uses explicit page frames. Users create multiple frames (for example, four frames), then enlarge or reposition diagram elements so they align with those frame borders. When printing, the output follows the frame layout, so the boundaries where figures are split land on the intended page edges, producing cleaner, more predictable cuts.

What controls the order in which frames/pages print?

Each frame has a page number and printing follows alphabetical order based on frame names. Renaming a frame to something like “xxx” moves it toward the end of the sequence. This lets users override the default arrangement when the desired reading order doesn’t match the initial grid placement.

When should “print empty pages” be turned on or off?

If a document includes unused frames or templates reserve space, turning “print empty pages” off avoids printing trailing blank pages. Turning it on includes those empty frames as additional pages at the end—useful only when blank pages are intentionally part of the output. For templates, the off setting prevents template placeholders from showing up in final prints.

How can frame page labels be hidden without breaking the layout?

Users can open the Obsidian command palette and access “Excel frame settings.” From there, they can hide the frame name (page label) while keeping the frame outline/structure needed for correct printing. The result is a cleaner diagram view while preserving the frame-driven page breaks.

What limitation applies to custom page sizes in the wizard?

Custom sizes are allowed, but every frame must be the same size. Users create one custom-sized frame with the frame tool, then add additional frames in the page manager that match that exact size. Printing then respects the custom dimensions consistently across all pages.

How do templates make this workflow faster for new drawings?

In Obsidian, users configure a template file or folder, open the page layout wizard, and pre-create the frame grid (e.g., five pages down and five pages across). They can hide frame names in frame settings for a cleaner template. After saving (Ctrl+S), any new Excalidraw drawing using that template automatically inherits the frame layout, so printing produces the same multi-page cut pattern without manual frame setup.

Review Questions

If two frames have different names, how does the wizard decide which one prints first?
What happens to the final PDF when “print empty pages” is toggled on versus off in a template-based workflow?
Why must all frames share the same size when using custom page dimensions?

Key Points

1
Use the Printable Layout Wizard’s frame grid to control where Excalidraw elements are cut across pages, avoiding the unpredictable results of “fit to pages” exporting.
2
Create the exact number and arrangement of frames you need (e.g., four frames for a 2x2 layout), then resize/reposition the diagram to align with frame borders.
3
Control print order by naming frames, since printing follows alphabetical order of frame names.
4
Use the “print empty pages” toggle to exclude blank template frames from the final PDF when placeholders shouldn’t appear.
5
Hide frame name labels via Obsidian command palette “Excel frame settings” to keep the workspace clean.
6
Custom page sizes are supported, but every frame must match the same dimensions for consistent printing.
7
Install and access the script through Obsidian’s tools panel installer/update scripts, then optionally pin it for one-click use.

Highlights

Printing follows the frame borders, producing cleaner figure cut points than “fit to four pages” export.

Frame names determine print sequence through alphabetical ordering, enabling deliberate reading order.

A “print empty pages” setting prevents template placeholders from turning into blank PDF pages.

Custom page sizes work as long as every frame is the same size.

Templates let new drawings inherit a prebuilt multi-page frame layout automatically.

Topics

Printable Layout Wizard
Excalidraw Printing
Frame-Based PDF Layout
Obsidian Templates
Script Installation
