Build a sketch-note slideshow with Obsidian, Excalidraw and QuickAdd

Sketch-note presentations in Excalidraw can be turned into a slide deck inside Obsidian by using QuickAdd macros plus a small set of JavaScript automations. The core idea is to pre-label parts of a drawing as nested “groups,” then capture the group IDs into a navigation file, and finally use hotkeys to move forward/backward while zooming the canvas to the matching group—without manually hunting for the right view each time.

The workflow starts with structuring the Excalidraw file. The drawing is organized into groups (including groups-within-groups), where each top-level group represents one “slide area.” A capture macro runs against the active Excalidraw view, reads the currently selected elements, and identifies the “largest” selected group by counting which group contains the most items. That chosen group’s ID becomes the next entry in a navigation file.

Navigation is stored as a simple text list of group IDs. A key detail is that the navigation file’s first line is intentionally left empty so the opening slide can be the entire drawing; removing that empty line would shift the deck so the first slide becomes the first group instead of the full canvas. The navigation file path is derived from the currently open document: the script strips the file extension and appends “-navigation,” so each Obsidian note gets its own deck metadata.

Presentation mode is handled in two phases. First, a “start presentation” macro forces Excalidraw into full-screen mode (if it isn’t already) and initializes a slide counter to -1 in local storage. That -1 matters because Excalidraw group indexing starts at 0; the next step increments the counter so the first displayed view becomes slide 0 (the whole drawing). Second, forward/back hotkeys update the slide counter, wrap around at the ends of the deck, and then zoom to the correct group.

The zoom logic reads the navigation file, splits it by newline into an array of group IDs, and selects the group ID for the current slide. It then fetches all Excalidraw scene elements and filters them by whether each element’s draw group IDs “includes” the target slide group ID. Finally, Excalidraw’s zoom-to-fit is called with the filtered elements, focusing the canvas on the exact region meant for that step of the explanation.

QuickAdd ties everything together with four hotkey-driven choices: capture group IDs to the navigation file, start presentation, move to the next slide, and move to the previous slide. The capture choice writes group IDs to the bottom of the navigation file so slides accumulate in order. During presentation, the scripts rely on local storage to persist the current slide index across hotkey presses.

Editing the required JavaScript in Obsidian is handled via two options: create a scripts folder and edit .js files externally, or install a “Code View” plugin (not published in the community plugins) to edit scripts inside Obsidian. The setup also includes a practical shortcut: a downloadable zip of the five scripts and a data.json file for QuickAdd, plus an optional setting to “detect all file extensions” so the scripts appear in file explorer.

For people who want zero scripting, the alternative is a manual presentation approach: switch Excalidraw to view mode (read-only), go full screen, and use the control + mouse wheel to zoom to the next region while presenting. The scripted method trades manual zooming for repeatable, hotkey-driven slide navigation that stays aligned with the group structure inside the drawing.
