Importance Performance MAP Analysis using #SmartPLS4

Importance Performance Map Analysis (IPMA) in SmartPLS is a prioritization tool that ranks predictors by two things at once: how strongly they matter for an outcome (importance via unstandardized total effects) and how well they’re currently performing (performance via rescaled latent variable scores). The practical payoff is clear—constructs that sit in the “high importance, low performance” quadrant signal the biggest opportunity for improvement because boosting them is expected to raise the target outcome.

In IPMA, importance comes from the total effect of an antecedent construct on the target endogenous construct, combining direct and indirect paths. Performance is measured as the construct’s average latent variable score, rescaled to a 0–100 scale so that higher values reflect stronger performance. Plotting these two dimensions on a single map—importance on the x-axis and performance on the y-axis—creates four quadrants that guide managerial action. The lower-right region is the focal zone: constructs there have high total effects on the target but relatively low performance, meaning they are influential yet under-delivering. Improving such predictors should translate into measurable gains in the outcome.

SmartPLS automates most of the workflow, but the setup has strict requirements. First, all indicators feeding the latent variables must use metric or quasi-metric scales, and their coding direction must be consistent: the minimum value should represent the worst outcome and the maximum the best. Reverse-coded items must be flipped before analysis. Second, the outer weights (outer WDs) must be positive; negative outer weights can push latent variable scores outside the expected 0–100 range (for example, drifting toward values like -5 to 95). If negative weights appear, the transcript highlights typical causes—reverse coding mistakes, nonsignificant negative weights that may justify removing indicators, or collinearity problems where VIF values of 5 or higher suggest indicator redundancy.

Once requirements are satisfied, SmartPLS computes performance and importance values and generates the map. The map is divided by average-based thresholds into regions of low/high importance and low/high performance. Constructs in the lower-right quadrant are treated as high-priority improvement targets.

A worked example uses “loyalty” as the outcome. Two constructs—commitment and service innovation—land in the high-importance but low-performance area. The session then demonstrates how to quantify impact: if a predictor’s performance increases by one unit, the expected change in the outcome equals the predictor’s importance (total effect) added to the outcome’s current rescaled score. For commitment, the example uses an importance value of 0.425; raising commitment performance by one unit is shown as increasing loyalty performance by that amount. For service innovation, the importance value is 0.617, and the same one-unit logic is applied to estimate the resulting loyalty improvement.

Finally, IPMA can be extended from construct level to indicator level. Indicators that are important but not performing can be targeted directly, using the same principle: a one-unit improvement in an indicator’s performance increases the outcome’s performance by that indicator’s importance value. The overall message is operational—IPMA turns model results into a concrete “what to fix first” plan for improving the target outcome.
